G07
G08
G10A
G10W
Handheld Integrated Ground Station
Parameter
System
Android 9
CPU
Qualcomm- 8 Core
SSD Storage & RAM
4G & 32GB
Network
Support 4G (2.4G / 5.8G Wifi, Bluetooth 4.0)
Screen
7-inch Touch Screen, 1920*1200 Resolution
External Interface
1*USB 2.0 / 1*HDMI / 1*TF / 1*SIM / 1*Type-C
Brightness
1500nit
Size
275*140*30.5mm
Battery
12.6V 5AH
Working Hours
5-6 h
Weight
1.1 kg
Temperature
-20~60℃
Control Output
2*SBUS Output，16 Channels
Channels Type
2 * Joysticks / 2 * Wave Wheels / 2 * Toggle Switchs / 2 * Knobs / 9 * Buttons
Frequency Band
800Mhz / 1.4Ghz / 2.4Ghz (Automatic Frequency Hopping )
Transmission Distance
10-15 km
Transmission Power
25 dbm
Air Interface
2*S-BUS / 1*RS232 / 1*TTL / 1*RJ45 / 1*XT30
Handheld Integrated Ground Station
Parameter
System
Android 12
CPU
RK3588-8 Core（Made in China）
SSD Storage & RAM
8G & 64GB（Customizable）
Network
Supports 4G (2.4G wifi, Bluetooth 4.0)
Screen
8-inch Touch Screen, 1920*1200 Resolution
External Interface
1*USB 2.0 / 1*HDMI / 1*TF /1*SIM / 1*Type-C
Brightness
1000nit
Size
290*160*60 mm
Battery
12.6V 9AH
Working Hours
6-7 h
Weight
1.5 kg
Temperature
-20~60℃
Control Output
2*SBUS Output，16 Channels
Channels Type
3*Joysticks / 6*Toggle Switchs / 2*Knobs / 10*Buttons
Frequency Band
800Mhz / 1.4Ghz / 2.4Ghz (Automatic Frequency Hopping)
Transmission Distance
10-15 km
Transmission Power
25 dbm
Air Interface
2*S-BUS / 1*RS232 / 1*TTL / 1*RJ45 / 1*XT30
Handheld Integrated Ground Station
Parameter
System
Android 12
CPU
Loading RK3588 Eight Core
SSD Storage & RAM
4G & 32GB（Customizable）
Network
Support 4G (2.4G Wifi, Bluetooth 4.0)
Screen
10.1-inch Touch Screen, 1920*1200 Resolution
External Interface
1*USB 2.0 / 1*HDMI / 1*TF / 1*SIM
Brightness
1000nit
Size
335*184*69mm
Battery
12.6V 12AH
Working Hours
5-6 h
Weight
1.9 kg
Temperature
-20~60℃
Control Output
2*SBUS Output，22 Channels
Channels Type
3* Joysticks / 6 * Toggle Switchs / 2*Knobs / 10*Buttons
Frequency Band
800 Mhz / 1.4 Ghz / 2.4 Ghz
Transmission Distance
22 km
Transmission Power
30 dbm
Air Interface
2*S-BUS / 1*RS232 / 1*TTL / 1*RJ45 / 1*XT30
Handheld Integrated Ground Station
Parameter
System
Windows 10 / Linux
CPU
Intel I7-10510U
SSD Storage & RAM
8G & 256GB（Customizable）
Network
2.4G/5.8G Wifi, Bluetooth 4.0
Screen
10.1-inch Touch Screen， 1920*1200 Resolution
External Interface
2*USB 3.0 / 1*HDMI / 1*LAN / 2*SMA-KF
Brightness
1000nit
Size
335*185*78 mm
Battery
16.8V 9AH
Working Hours
4-6 h
Weight
1.9 kg
Temperature
-20~60℃
Control Output
2*SBUS Output，16 Channels / USB-HID
Channels Type
3*Joysticks /6*Toggle Witchs / 2*Knobs / 10*Buttons
Frequency Band
800Mhz / 1.4Ghz / 2.4Ghz
Transmission Distance
10-22 km
Transmission Power
30 dbm
Air Interface
2*S-BUS / 1*RS232 / 1*TTL / 1*RJ45 / 1*XT30
