M10
M30
M50
Data Link
Parameter
Frequency Range
5.8GHz Frequency Band：5.15GHz~5.85G
Transfer Rate
Adaptive，≤100Mbps
Maximum Transmission Power
30dBm（2T2R）
Communication Distance
10-15KM（Intervisibility）
Sensitivity
-99dBm
Network Topology
Point to point/Point-to-Multipoint/Relay/MESH
External Interface
2*SMA、1*SBUS、1*TTL、1*RJ45
Antenna Gain
Air：5dBi / Ground：Directional 14 dBi，Omnidirectional 5dBi
Modulation Mode
LR-WIFI
Antenna Standing Wave Ratio
≦5W
Temperature
-40~70℃
Sky End Size
72*64*12mm
Weight
53g
Power Supply Range
DC9-72V
Data Link
Parameter
Frequency Range
1.4GHz Frequency Band：1300MHz~1500 MHz(Customizable)
Channel Bandwidth
1.25MHz/2.5/10MHz/20MHz
Output Power
1W*2（2T2R）
Communication Distance
1-30KM（Intervisibility）
Sensitivity
≤-103dBm@5MHz BW
Air Unit External Interface
2*MMCX/1*SBUS/1*TTL/1*RJ45
Ground Unit External Interface
1*N-KF / 1*TTL/1*S-BUS/1*RJ45
Antenna Type
Air：Glue Stick Antenna 14cm / Ground：Flat Directional Antenna 25 cm x 25 cm
Antenna Gain
Air：2dBi / Ground：Directional 12 dBi，Omnidirectional 6 dBi
Modulation Mode
TD-COFDM
Antenna Standing Wave Ratio
≤8.5W
Temperature
-40~70℃
Sky End Size
117*62*19mm
Weight
149g
Power Supply Range
DC9-32V
Data Link
Parameter
Frequency Range
1.4GHz Frequency Band：1300MHz~1500 MHz(Customizable)
Channel Bandwidth
1.25MHz/2.5/10MHz/20MHz
Output Power
2W*2（2T2R）
Communication Distance
1-50KM（Intervisibility）
Sensitivity
≤-103dBm@5MHz BW
Air Unit External Interface
2*MMCX/1*SBUS/1*TTL/1*RJ45
Ground Unit External Interface
1*N-KF / 1*TTL/1*S-BUS/1*RJ45
Antenna Type
Air：Glue Stick Antenna 14cm / Ground：Flat Directional Antenna 25 cm x 25 cm
Antenna Gain
Air：2dBi / Ground：Directional 12 dBi，Omnidirectional 6 dBi
Modulation Mode
TD-COFDM
Antenna Standing Wave Ratio
20W
Temperature
-40~70℃
Sky End Size
117*62*19mm
Weight
149g
Power Supply Range
DC9-32V
